Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants

  • 1
  • 2

Brand Name : LANRY

Model Number : DOF6000-W

Certification : CE

Place of Origin : Shanghai, China (Mainland)

MOQ : 1 Unit

Price : Negotiable

Supply Ability : 100pcs /week

Packaging Details : carton package

Product Name : Doppler open Channel Flow meter

Accuracy : 1% of reading from 1.5 to 4.5m/s

Power supply : 85~265VAC, 12~28VDC（Wall-Mounted)

Operating temperature : -20℃ to +60℃

Size : 244*196*114mm(Wall-Mounted);

Degree of Protection : IP66

Contact Now

Doppler open Channel Ultrasonic Flow meter DOF6000-W of Wall-Mounted Type
Doppler flow meter DOF6000 Widely used in sewage plants, sewage outfall of enterprises and
institutions, city sewer flows and irrigation Channels and so on. DOF6000 series DOF6000 Digital
River Water Flow Meter consists of flow calculator, and the integrated DOF6526 transducer to
measure velocity and level at the same time.
The Doppler Open channel flowmeter is suitable for variou applications, the Ultrasonic Flow meter
can calculate the cross-sectional area of partially filled pipe, open channel stream or river, for stream or river, Ultrasonic Flow meter can input up to 20 coordinate points describing the river's shape of
cross section.
Ultrasonic Flow meter also can be available with 4-20mA, RS232, RS485 (Modbus) /GPRS and SD
card logger outputs.
Doppler open Channel Ultrasonic Flow meter DOF6000-W of Wall-Mounted Type Features:

1. Measure flow in partially filled pipes and open channels.
2. 16GB SD card data logger can be optional.
3. Display the velocity, level, flow rate and flow totalizer.
4. No flume or weir required.
5. 20 coordinate points to describe the river’s shape of cross section.
6. 4-20mA, RS485 (Modbus) /GPRS outputs are available.

Application
Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants

Wall-Mounted Doppler type Ultrasonic Flowmeter DOF6000-W Specifications:

Calculator:
Enclosure typeWall-Mounted
Power Supply:85~265VAC,12~28 VDC(Wall-mounted)
Degree of protectionIP65
Operating temperature-20℃ to +60℃
Application rangePipe: 300-6000mm, Channel: 200-6000mm
Outputs:4-20mA, RS485(Modbus), data logger, GPRS (optional)
Enclosure MaterialFiberglass(Wall-mounted)
Size244L×196W×114H (mm)
Data logger16GB
Weight2.4kg

Specifications :DOF6526 sensor

DOF6526 sensor:

Depth

Range:

0m to 3.0m or 0m to 6.0m

Accuracy:

±0.25% of calibrated lower range

Resolution:

H2 0-1m at 1mm, 1-2m at 2mm
H5 0-2.5m at 2.5mm, 2.5-5m at 5mm

Velocity

Range:

21mm/s to 4500mm/s bi-directional

Accuracy:

2% of measured velocity

Resolution

1mm/s

Temperature

Temperature:

-17°C to 60°C

Resolution:

0.1°C

General

Cable:

15M

Cable Options:

User specified up to 100 meters

Material:

PVC body, stainless steel mounting plate

Dimensions:

290mm x 70mm x 30mm (L x W x H)

Weight:

1kg (2kg with 15m cable)

FlowComputation:0.1°C
Channel type:Flow rate, flow totalizer
Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants
Installation details:
Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants

Customer visiting

Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants

Exhibition visiting
Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants
Packing & Delivery

Packing

Wall-Mounted Doppler type Ultrasonic Flowmeter DOF6000-W 200-6000mm for Open Channel Application
With years of export experience along with excellent quality, advanced services and competitive
prices, Lanry has won numerous customers' trust and support.With years of export experience
along with excellent quality, advanced services and competitive prices, Lanry has won
numerous customers' trust and support.

Doppler Area Velocity Flow Meter 244*196*114mm For Sewage PlantsDoppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants

Delivery

Wall-Mounted Doppler type Ultrasonic Flowmeter DOF6000-W 200-6000mm for Open Channel Application
Standard meter: 3-7 days
Special meter: pls feel free to contact us
Express, by air, by sea can be optional.

Certificates:
Doppler Area Velocity Flow Meter 244*196*114mm For Sewage Plants
