30 Year's Technology Insertion Ultrasonic Flow Meter provides abundant capabilities for accurate liquid flow measurement from outside of a pipe. It utilizes state-of-the-art technologies on ultrasonic transmission /receiving, digital signal processing and transit-time measurement. The proprietary signal quality tracking and self-adapting technologies allow system to optimally adapt to different pipe materials automatically. Due to hot-tapped mounting of insertion transducers, there is no ultrasonic compound and coupling problem; Even though the transducers are inserted into pipe wall, they do not intrude into the flow, thus, do not generate disturbance or pressure drop to the flow. The insertion (wetted) type has the advantage of long-term stability and better accuracy.
Features:
1. Calculator can be hung at the body or installed separately. Distance apart could be up to 10 meter.
2. Internal 3.6V high capacity lithium battery,external AC220V or DC24V optional
3. Unique design for fluid structure to improve measuring accuracy and stability and reduce the requirement for straight piping during installation to up 5 and down 0.
4. IP68 grade
5. Can be mounted in flow pipe or in return pipe, and can be mounted in horizontal or vertical installation for different customer requirements.
6. Complies CJ/188, GB/26831,MODBUS RTU and EN13757 communication protocol
7. Support optical,RS485, wire and wireless M-Bus, short message, GPRS, pulse output interfaces, convenient for user to manage data in different manners.
8. 4~20 mA output optional.
9. Complies with AGFW NOWA protocol
Application:
RCN82 Series ultrasonic heating (cooling, heating-cooling) meters are used for energy measurement of heating or chilled water. They are available in DN40-1000 and have an electronic energy calculator with separate register for heating and cooling energy. They are fitted with an M-Bus interface for integration into M-Bus networks.
Technical Features
Up 5 down 0 straight piping installation
More than 10 year shelf life
Wireless transmission
Pressure Loss Curve
Company profile
Lanry Instruments is the professional manufacturer of flow detection instruments, provides one package service of re- search and development, production, marketing and after-sales services. Engaged in the production of flow instruments more than 20 years, Lanry has been equipped with advanced design capabilities and piled up a wealth of field application experience, which lays solid foundation for the commitment to the promotion and innovation of high-tech system solution. The corporation has devoted to the production of flow measurement instruments with superior performance, high stability and strong reliability. Currently, Lanry Instruments has developed into two branches as Lanry Instruments (Shanghai) Co., Ltd. and Lanry instruments (Dalian) Co., Ltd, which are responsible for different areas and applications.Adhering to the "high quality, high efficiency " business principles, Lanry instruments takes quality as its life. Sticking to the "integrity innovation, win-win" development principles, we do sincere business and sets sights on technology innovation. Therefore, it is believed that with the top-class product quality, first-class business management and first-ranking customer service, the corporation is supposed to cooperate sincerely,develop mutually and then create brilliance together with customers!
With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support all over the world.
